Raw Material

• Low carbon steel wire / galvanized wire / stainless steel wire
• Coil or pre-cut wire feeding system

 Wire Diameter Range

• 1.5 mm – 6 mm (varies by model)
• Heavy-duty models: up to 8 mm for reinforcement mesh

 Mesh Size (Opening)

• Adjustable: 25 × 25 mm to 300 × 300 mm
• Custom spacing available via PLC settings

 Mesh Width

• Standard: 1 m – 3 m
• Common maximum width: 2 m – 3 m

Mesh Length

• Panel type: up to 6 m – 12 m
• Roll type: up to 100 m+ continuous production

 Welding System

• Resistance welding technology
• Multi-point automatic welding electrodes
• Welding transformers: approx. 50 kVA – 150 kVA per unit (multiple units)

Production Speed

• 40 – 120 welds per minute (depending on wire diameter and mesh size)

 Control System

• PLC (Programmable Logic Controller)
• Touch screen HMI interface
• Automatic fault alarm system

 Automation Functions

• Automatic wire feeding (longitudinal & cross wire)
• Automatic straightening & cutting (cross wire)
• Automatic welding
• Automatic mesh pulling and stacking/rolling

 Power Requirement

• 380V / 415V / 50Hz / 3 Phase
• Total power consumption depends on model (typically 50 kW – 200 kW)

 Machine Structure

• Heavy-duty steel frame body
• Water-cooled welding transformers (optional in heavy models)
• Pneumatic or servo-controlled systems

 Output Products

• Construction reinforcement mesh
• Fencing panels
• Industrial safety mesh
• Cages, racks, and protective mesh

 Applications

• Building construction (slabs, roads, bridges)
• Infrastructure reinforcement
• Agriculture fencing
• Industrial storage systems
